ARTIC TEC
LED EXPLOSIVE PROOF FIXTURE 18W
Product Overview
- Housing — aluminum alloy DC12
- Tempered glass, shock and vibration resistant
- Flicker-free, even light distribution
- Explosive proof level Ex d IIB T6 Gb
- 3 years warranty, 5 years warranty optional
- Area application: Sea Ports, Chemical or Food Factory, Laboratory.
- Install: Surface mounted.
Highlight
Ex d IIB T6 Gb
Housing — aluminum alloy DC12
Product Datasheet
| Item No. | FJ-EP01-18W |
|---|---|
| Power | 18W |
| Lumen Efficiency | 100lm/w |
| Lumen | 1800lm |
| Product Size | 1280×110 mm |
| Power Factor (PF) | >0.5 |
| Working Voltage | 175-245V, 50/60Hz |
| CCT | 3000k/4000k/6000k optional |
| CRI | 80 |
| Angle | 180° |
| IP Rating | IP65 |
| Explosion Proof | Ex d IIB T6 Gb |
| Body Material | Aluminum+Tempered Glass |
| Chips | SANAN |
| Driver Brand | Artic Tec |
| Working Temperature | -20°C ~ +55°C |
| Working Humidity | 10%-90% RH |
| Lifespan | 25,000hrs or 50,000hrs |
| Warranty | 3 years or 5 years |
| Housing Color | Grey |
| Reasonable Tolerance | Watt: ±10%, CCT: ±500K, Lumen efficiency: ±5% |
Dimension
Fixture information · AxBxC (mm)
| FJ-EP01-18W | 1280×110 |
|---|
Package information · AxBxC (mm) · PCS/carton
| FJ-EP01-18W | 1340×190×120 | 2 |
|---|
